An intelligent and flexible solution for the soft drinks industry

YOUR SOFT DRINK IN THE BEST POSSIBLE CONDITION WITH A THIELMANN CORNELIUS STYLE KEG

The THIELMANN Cornelius Style Keg, also referred to as a “Corny Keg”, is constructed using high quality and durable stainless steel (AISI 304) and is the ideal vessel for the pressurized storage and transportation of “pre-mix” soda commonly used within the soft drinks industry.

The main benefit of using a Cornelius style keg is the simple manual access via the oval handhole which facilitates safe and easy opening, filling and cleaning, thus removing the need for investment in, sometimes costly, industrial filling and washing equipment.

The keg features a removable lid and two ball lock connections for gas in and liquid in, facilitating a quick and simple connection for gas and liquids respectively.

THIELMANN Cornelius Style kegs are available in a range of different sizes and formats, to meet the specific needs of the Beverage Industry and represent a flexible and cost-effective solution. Choose between two different diameter sizes, the ø237mm option is specified with rubber at both the top and bottom, or the ø216mm format which features a rubber bottom as standard, however can be specified as a stainless steel bottom depending on your requirements.

There is a myriad of further personalization options available, such as, branding options to showcase your customer logo, and a choice of stainless steel grades, including 1.4301 /1.4404 and 1.4571.

Industries

  • Beverage
  • Food

ø237 Diameter:

  • Equipped with oval cap pressure relief valve
  • Container material in stainless steel grades of 1.4301 1.4571 or 1.4404.
  • Upper and lower SBR rubber rings
  • Rubber top features an integrated handle
  • Connections: liquid and gas connection equipped with quick release valve. Our valves are made of stainless steel 1.4404 (AISI316L), which are clearly coded to avoid connection errors.
  • Personalization options including branding and labelling options
  • Designs can be personalized

ø216 Diameter:

Lower ring: Rubber

Upper ring: None or alternatively stainless steel ring option

  • Equipped with oval cap pressure relief valve
  • Container material in stainless steel grades of 1.4301 1.4571 or 1.4404.
  • SBR rubber bottom
  • PP or Inox handle available
  • Connections: liquid and gas connection equipped with quick release valve. Our valves are made of stainless steel 1.4404 (AISI316L), which are clearly coded to avoid connection errors.
  • Personalization options including branding and labelling options
  • Designs can be personalized

Our raw material suppliers receive very precise instructions regarding the standards that have to be adhered to in order to satisfy our stringent quality requirements of the kegs to be manufactured.

Advantages

  • Safety guaranteed for food and beverages
  • Non-corrosive steel
  • Extreme resistance in comparison with other materials
  • 100% UV resistant
  • 100% recyclable. Saves CO2
  • Long product lifetime
  • Fully customizable – branding and labelling options available
  • Beer
  • Wine
  • Cider
  • Water
  • Juice
  • Soft Drinks
  • Cold Brew Coffee
  • Cocktails
  • Spirits
  • Kombucha
